Reducer ORFS Erkak ayollar uchun armatura

Reducer ORFS Erkak ayollar uchun armatura

Mahsulot turlari: 5F-S o halqali yuza muhrlangan naychali armatura Sanoat standartlari: SAE J1453, ISO 8434-3, SAE J514, ISO 8434-2 E uslubini F uslubiga ulash: ORFS MALE / ORFS FEMALE Shakli: Tirsak, tekis, Tee, Xoch. va hokazo. ORFS armatura: Ish bosimi darajasi: 3215 psi dan 5800 psi gacha, 216 bar dan 400 bargacha. Yassi yuz ...
So'rov yuborish
5F-S o halqa naychali armatura
Hozir chat
Ta'rif

Mahsulot turlari: 5F-S o ringli yuz muhrlangan naychali armatura

Sanoat standartlari: SAE J1453, ISO 8434-3, SAE J514, ISO 8434-2

E F uslubiga ulanish: ORFS MALE / ORFS FEMALE

Shakl: tirsak, to'g'ri, Tee, xoch va boshqalar.

ORFS armatura ish bosimi darajasi: 3215 psi dan 5800 psi gacha, 216 bar dan 400 bargacha.

Yassi yuzli Orfs o ring o'lchamlari to'plami va O halqali yuz muhr dizayni biz ham taklif qilishimiz mumkin.

O ring yuzi muhr va o ring boss muhri o'rtasidagi farq

Armatura materiallari: guruch; Karbonli po'lat; Zanglamaydigan po'lat

Ilova: Qishloq xo'jaligi uskunalari, avtomobilsozlik, kimyoviy uzatish, qurilish uskunalari, yonilg'i quyish, gidravlik, ishlab chiqarish uskunalari, dengiz, materiallarga ishlov berish, mobil uskunalar, neft koni, qadoqlash, transport.

5F-S ORFS MALE / ORFS FEMALE O'lcham o'lchamlari jadvali quyidagicha:





PAR T   YO'Q .

THREA D

O   O-RIN G

DIMENSION S




E

F

E


A

C

L

S 1

Fi g



5F-04 S

9/16 "X1 8

9/16 "X1 8   O 01 1


9. 8

8. 5

18. 5

1 9

B


5F-04-06 S

9/16 "X1 8

11/16 "X1 6

O 01 1


9. 8

1 0

19. 6

2 2

B



5F-04-08 S

9/16 "X1 8

13/16 "X1 6

O 01 1


9. 8

1 1

21. 8

2 7

A



5F-04-10 S

9/16 "X1 8

1 "X1 4

O 01 1


9. 8

13. 5

22. 9

3 0

A



5F-04-12 S

9/16 "X1 8

1.3 / 16 "X1 2

O 01 1


9. 8

1 5

24. 9

3 6

A



5F-04-16 S

9/16 "X1 8

1.7 / 16 "X1 2

O 01 1


9. 8

14. 8

24. 9

3 6

A



5F-04-20 S

9/16 "X1 8

1.11 / 16 "X1 2

O 01 1


9. 8

1 5

24. 9

5 0

A



5F-06 S

11/16 "X1 6

11/16 "X1 6

O 01 2


11. 2

1 0

29. 7

2 2

B



5F-06-04 S

11/16 "X1 6

9/16 "X1 8

O 01 2


11. 2

8. 5

26. 7

1 9

B



5F-06-08 S

11/16 "X1 6

13/16 "X1 6

O 01 2


11. 2

1 1

22. 4

2 7

B



5F-06-10 S

11/16 "X1 6

1 "X1 4

O 01 2


11. 2

13. 5

24. 1

3 0

A



5F-06-12 S

11/16 "X1 6

1.3 / 16 "X1 2

O 01 2


11. 2

1 5

26. 5

3 6

A



5F-06-16 S

11/16 "X1 6

1.7 / 16 "X1 2

O 01 2


11. 2

14. 8

26. 5

4 1

A



5F-06-20 S

11/16 "X1 6

1.11 / 16 "X1 2

O 01 2


11. 2

1 5

26. 5

5 0

A



5F-08 S

13/16 "X1 6

13/16 "X1 6

O 01 4


12. 8

1 1

2 4

2 7

B



5F-08-04 S

13/16 "X1 6

9/16 "X1 8

O 01 4


12. 8

8. 5

2 2

1 9

B



5F-08-06 S

13/16 "X1 6

11/16 "X1 6

O 01 4


12. 8

1 0

2 4

2 2

B



5F-08-10 S

13/16 "X1 6

1 "X1 4

O 01 4


12. 8

13. 5

25. 7

3 0

B



5F-08-12 S

13/16 "X1 6

1.3 / 16 "X1 2

O 01 4


12. 8

1 5

27. 7

3 6

A



5F-08-16 S

13/16 "X1 6

1.7 / 16 "X1 2

O 01 4


12. 8

14. 8

29. 2

4 1

A



5F-08-20 S

13/16 "X1 6

1.11 / 16 "X1 2

O 01 4


12. 8

1 5

29. 2

5 0

A



5F-10 S

1 "X1 4

1 "X1 4

O 01 6


15. 5

13. 5

2 9

3 0

A



5F-10-06 S

1 "X1 4

11/16 "X1 6

O 01 6


15. 5

1 0

26. 5

2 2

A



5F-10-08 S

1 "X1 4

13/16 "X1 6

O 01 6


15. 5

1 1

27. 5

2 7

A



5F-10-12 S

1 "X1 4

1.3 / 16 "X1 2

O 01 6


15. 5

1 5

29. 5

3 6

A



5F-10-16 S

1 "X1 4

1.7 / 16 "X1 2

O 01 6


15. 5

14. 8

3 2

4 1

B



5F-10-20 S

1 "X1 4

1.11 / 16 "X1 2

O 01 6


15. 5

1 5

31. 5

5 0

B



5F-12 S

1.3 / 16 "X1 2

1.3 / 16 "X1 2

O 01 8


1 7

1 5

3 1

3 6

A



5F-12-06 S

1.3 / 16 "X1 2

11/16 "X1 6

O 01 8


1 7

1 0

2 8

2 2

A



5F-12-08 S

1.3 / 16 "X1 2

13/16 "X1 6

O 01 8


1 7

1 1

2 9

2 7

A



5F-12-10 S

1.3 / 16 "X1 2

1 "X1 4

O 01 8


1 7

13. 5

30. 5

3 0

A



5F-12-16 S

1.3 / 16 "X1 2

1.7 / 16 "X1 2

O 01 8


1 7

14. 8

33. 5

4 1

A



5F-12-20 S

1.3 / 16 "X1 2

1.11 / 16 "X1 2

O 01 8


1 7

1 5

33. 5

5 0

B



5F-12-24 S

1.3 / 16 "X1 2

2 "X1 2

O 01 8


1 7

14. 8

33. 5

6 0

B



5F-16 S

1.7 / 16 "X1 2

1.7 / 16 "X1 2

O 02 1


17. 5

14. 8

33. 5

4 1

A



5F-16-04 S

1.7 / 16 "X1 2

9/16 "X1 8

O 02 1


17. 5

8. 5

2 7

1 9

A



5F-16-06 S

1.7 / 16 "X1 2

11/16 "X1 6

O 02 1


17. 5

1 0

2 8

2 2

A



5F-16-08 S

1.7 / 16 "X1 2

13/16 "X1 6

O 02 1


17. 5

1 1

2 9

2 7

A



5F-16-10 S

1.7 / 16 "X1 2

1 "X1 4

O 02 1


17. 5

13. 5

30. 5

3 0

A



5F-16-12 S

1.7 / 16 "X1 2

1.3 / 16 "X1 2

O 02 1


17. 5

1 5

3 1

3 6

A



5F-16-20 S

1.7 / 16 "X1 2

1.11 / 16 "X1 2

O 02 1


17. 5

1 5

3 2

5 0

C



5F-16-24 S

1.7 / 16 "X1 2

2 "X1 2

O 02 1


17. 5

14. 8

3 2

6 0

A



5F - 20 S

1.11 / 16 "X1 2

1.11 / 16 "X1 2

O 02 5


17. 5

1 5

34 .5

5 0

C



5F-20-12 S

1.11 / 16 "X1 2

1.3 / 16 "X1 2

O 02 5


17. 5

1 5

3 2

3 6

B



5F-20-16 S

1.11 / 16 "X1 2

1.7 / 16 "X1 2

O 02 5


17. 5

14. 8

3 2

4 1

B



5F-20-24 S

1.11 / 16 "X1 2

2 "X1 2

O 02 5


17. 5

14. 8

34. 3

6 0

A



5F - 24 S

2 "X1 2

1.11 / 16 "X1 2

O 02 9


17. 5

14. 8

36 .5

6 0

C



5F-24-20 S

2 "X1 2

1.11 / 16 "X1 2

O 02 9


17. 5

1 5

35. 5

5 0

C
