Mahsulot kategoriyasi: Suyuq quvvatni trubkali ulash uchun JIC gidravlik moslashtiruvchi adapterlar
Mahsulot standarti: ISO 8434-2, SAE J514.
Material: uglerodli po'lat, zanglamaydigan po'lat yoki mis qotishma.
JIC naychasining uchi boshqa so'nggi ulanishga ulanadi: BSP tutqichli muhr E, G, H turlari, ISO 6149 seriyali armatura, JIS B2351 qismlari, ISO 11926 va SAE J1926 ORB armatura, DIN 3852 va ISO 1179 qismlari, ISO 9974 qismlari va boshqalar.
1JO9-OG 90 ° ELBOW JIC MALE 74 ° CONE / SAE O-RING BOSS L-SERIES ISO 11926-3 o'lchov jadvali quyidagicha:
PA RT N O | T HR EA D | O O- RING | DIM E N S I O NS | |||||
E | F | F | A | B | S 1 | S 2 | ||
1 JO' 9 - 04 - 03 O G | 7/16 " X 20 | 3/8 " X 24 | O 903 | 24.5 | 28 | 11 | 14 | |
1 JO 9 - 04 O G | 7/16 " X 20 | 7/16 " X 20 | O 904 | 24.5 | 27.2 | 11 | 17 | |
1 JO' 9 - 04 - 05 O G | 7/16 " X 20 | 1/2 " X 20 | O 905 | 26.6 | 29.9 | 14 | 17 | |
1 JO 9 - 04 - 06 O G | 7/16 " X 20 | 9/16 " X 18 | O 906 | 26.6 | 31.8 | 14 | 19 | |
1 JO' 9 - 05 - 04 O G | 1/2 " X 20 | 7/16 " X 20 | O 904 | 26.6 | 30 | 14 | 17 | |
1 JO' 9 - 05 O G | 1/2 " X 20 | 1/2 " X 20 | O 905 | 26.6 | 29 | 14 | 17 | |
1 JO' 9 - 05 - 06 O G | 1/2 " X 20 | 9/16 " X 18 | O 906 | 26.6 | 31.8 | 14 | 19 | |
1 JO' 9 - 06 - 04 O G | 9/16 " X 18 | 7/16 " X 20 | O 904 | 26.9 | 30 | 14 | 17 | |
1 JO' 9 - 06 - 05 O G | 9/16 " X 18 | 1/2 " X 20 | O 905 | 26.9 | 29.9 | 14 | 17 | |
1 JO' 9 - 06 O G | 9/16 " X 18 | 9/16 " X 18 | O 906 | 26.9 | 31.8 | 14 | 19 | |
1 JO' 9 - 06 - 08 O G | 9/16 " X 18 | 3/4 " X 16 | O 908 | 30 | 36,8 | 19 | 24 | |
1 JO' 9 - 08 - 04 O G | 3/4 " X 16 | 7/16 " X 20 | O 904 | 32 | 33 | 19 | 17 | |
1 JO' 9 - 08 - 06 O G | 3/4 " X 16 | 9/16 " X 18 | O 906 | 33 | 33.5 | 19 | 19 | |
1 JO' 9 - 08 O G | 3/4 " X 16 | 3/4 " X 16 | O 908 | 33 | 36,8 | 19 | 24 | |
1 JO' 9 - 08 - 10 O G | 3/4 " X 16 | 7/8 " X 14 | O 910 | 34,8 | 44 | 22 | 27 | |
1 JO' 9 - 08 - 12 O G | 3/4 " X 16 | 1.1 / 16 " X 12 | O 912 | 37.9 | 51 | 27 | 32 | |
1 JO' 9 - 10 - 08 O G | 7/8 " X 14 | 3/4 " X 16 | O 908 | 38 | 40 | 22 | 27 | |
1 JO 9 - 10 O G | 7/8 " X 14 | 7/8 " X 14 | O 910 | 37,8 | 44 | 22 | 27 | |
1 JO' 9 - 10 - 12 O G | 7/8 " X 14 | 1.1 / 16 " X 12 | O 912 | 41 | 51 | 27 | 32 | |
1 JO' 9 - 12 - 08 O G | 1.1 / 16 " X 12 | 3/4 " X 16 | O 908 | 45 | 44 | 27 | 24 | |
1 JO' 9 - 12 - 10 O G | 1.1 / 16 " X 12 | 7/8 " X 14 | O 910 | 44.2 | 47 | 27 | 27 | |
1 JO 9 - 12 O G | 1.1 / 16 " X 12 | 1.1 / 16 " X 12 | O 912 | 44.2 | 51 | 27 | 32 | |
1 JO' 9 - 12 - 16 O G | 1.1 / 16 " X 12 | 1,5 / 16 " X 12 | O 916 | 47,8 | 54.5 | 33 | 41 | |
1 JO' 9 - 14 O G | 1.3 / 16 " X 12 | 1.3 / 16 " X 12 | O 914 | 47.5 | 53 | 30 | 36 | |
1 JO' 9 - 14 - 16 O G | 1.3 / 16 " X 12 | 1,5 / 16 " X 12 | O 916 | 48.5 | 54.5 | 33 | 41 | |
1 JO' 9 - 16 - 12 O G | 1,5 / 16 " X 12 | 1.1 / 16 " X 12 | O 912 | 48,8 | 54.5 | 33 | 32 | |
1 JO' 9 - 16 - 14 O G | 1,5 / 16 " X 12 | 1.3 / 16 " X 12 | O 914 | 49 | 56 | 33 | 36 | |
1 JO' 9 - 16 O G | 1,5 / 16 " X 12 | 1,5 / 16 " X 12 | O 916 | 48,8 | 54.5 | 33 | 41 | |
1 JO' 9 - 16 - 20 O G | 1,5 / 16 " X 12 | 1,5 / 8 " X 12 | O 920 | 53.8 | 59 | 41 | 50 ga teng | |
1 JO' 9 - 20 - 16 O G | 1,5 / 8 " X 12 | 1,5 / 16 " X 12 | O 916 | 55.5 | 59.5 | 41 | 41 | |
1 JO 9 - 20 O G | 1,5 / 8 " X 12 | 1,5 / 8 " X 12 | O 920 | 55.3 | 59 | 41 | 50 ga teng | |
1 JO' 9 - 20 - 24 O G | 1.5 / 8 " X 12 | 1.7 / 8 " X 12 | O 924 | 59.4 | 63 | 48 | 55 | |
1 JO' 9 - 24 O G | 1.7 / 8 " X 12 | 1.7 / 8 " X 12 | O 924 | 62.5 | 63 | 48 | 55 | |
1 JO' 9 - 32 O G | 2.1 / 2 " x 12 | 2.1 / 2 " x 12 | O 932 | 80 | 76 | 63 | 70 | |
1 D NB 20 0 NB 50 0 NB 20 0 NB 30 0 2 F IS O 11926 - 1 yil N o t e 1 N u t bir d yengli ve shoul d b e o r de r e d sepa r a t el y . T h e nu t NB 20 0 bir d slee v e NB 50 0 i s sui t abl e f o r me tr i c t ube , t h e nu t NB 20 0 bir d slee v e NB 30 0 i s sui t abl e f o r inc h t ube . 2 F en d men s ulanish t e d w i th ISO 11926 - 1po rt. | ||||||||
